AIR-TO-WATER HEAT PUMPS – PRO SERIES – PACIFICA PRO KWEB
pacifica proKWEB
Air-to-water chillers and heat pumps |
high temperature up to 75ºC
29-120 kW32-132 kW
 |  |  |
▸ Ecodesign Manual COMFORT KWEB
Reversible or cooling-only heat pumps with heating capacities ranging from 32 kW to 132 kW, specifically designed for commercial, industrial, and centralized residential applications. Modular systems of up to 5 units are possible (up to 600 kW), with water temperatures reaching up to 75°C.
Optimized for the use of R-290 refrigerant and full-inverter technology, they stand out for their high energy efficiency and sustainability, expanding the range of PRO Series solutions developed by KEYTER.
- Compact Full-Inverter units equipped with hermetic scroll inverter compressors.
- High-quality EC fans and high-efficiency heat exchangers.
- Ensuring very high seasonal performance (average SEER 4.4 / SCOP35 4.7 / SCOP55 3.7).
- Wide operating range with high efficiency and extended operating limits (operation down to -20°C outdoor temperature at full load).
Series 2
| Bodywork | L | W | H |
|---|---|---|---|
| S/P | 1875 | 1100 | 2375 |
| H | 2975 | 1100 | 2375 |
Series 5
| Bodywork | L | W | H |
|---|---|---|---|
| S/P | 3260 | 1100 | 2375 |
| H | 4360 | 1100 | 2375 |
Series 6
| Bodywork | L | W | H |
|---|---|---|---|
| S/P | 3920 | 1100 | 2375 |
| H | 5020 | 1100 | 2375 |
PACIFICA PRO includes the programmable electronic control AQUAMATIX and user terminal Climatix HMI.
It is compatible with RS485 card for Modbus communication and BACnet IP communication system.
