11-194 kW  14-150 kW

7kg/h | 2000 m³/h – 311kg/h | 48000 m³/h

Adaptation and Versatility

   Fully adaptable and configurable units thanks to OPTIONAL FEATURES and with a wide variety of ASSEMBLIES with a mixing, free-cooling and energy reclaim section

   Units equipped with a sandwich panel painted on two faces with M0 mineral wool insulation (50 mm thick)

   Flexibility of assembly, both in indoor and outdoor machine rooms to suit the needs of each facility

   Combination of a compact design with maximum accessibility and easy maintenance thanks to panels that are easy to remove

   Low height for installation in indoor swimming pool tunnels

Energy efficiency

  Extraction air energy reclaim with reversible active recovery or via a cross-flow plate heat exchanger

   Heat reclaim to heat the pool water

   Free-cooling and dehumidification via outdoor air

   Electronic expansion valve and electronic plug fans for minimal energy consumption


Easy control

   Conditioned air temperature and humidity control

   CAREL supervision and electronic control with high performance and easy operation

   Wide variety of communication protocols (Modbus, BACnet and LonWorks)

Corrosion resistance

   Cooling compartment isolated from the airflow

   Plate heat exchanger to reclaim condensation heat

   Fans protected with epoxy paint or high-strength plastic

   BLUECOAST treatment of coils as standard

   Hydraulic connections made of high-strength cross-linked polyethylene

   Removable stainless steel condensate drain pan


Technical Documentation


More details about this product

The brand new Keyter Catalogue is out now and free available.

In this year’s edition you will discover our complete range of products and find more technical specifications about the Keyter units.


OCEAN units include DRYMANAGER electronic control with

 pGD1 terminal controller and DN33 control
